**Colin A. Simpfendorfer ^{a}, Ramón Bonfil^{b} and Robert J. Latour^{c}**

1600 Ken Thompson Parkway

Sarasota, Florida, 34236, USA

<[email protected]>

2300 Southern Blvd.

Bronx, New York, 10460, USA

<[email protected]>

College of William and Mary

Gloucester Point, Virginia, 23062, USA

<[email protected]>

**8.1 INTRODUCTION**

Mortality is an essential parameter in understanding the dynamics of any population and sharks are no exception. Without knowledge of how fast individuals are removed from a population it is impossible to model the population dynamics or estimate sustainable rates of exploitation or other useful management parameters. Two separate types of mortality occur in shark (or fish for that matter) populations. First, natural mortality (commonly referred to by the letter M), which is the loss to the population from natural sources such as predation, disease and old age, and second fishing morality (referred to by the letter F) which, as the name suggests, is the loss to the population from fishing. Fishing and natural mortality combine to give total mortality (referred to by the letter Z), such that

Z = M + F | (8.1) |

Mortality values are typically expressed as rates that are either instantaneous or finite (or apply to another fixed period). Instantaneous (distinguished here by an upper case letter) and finite rates (lower case letter) are related exponentially. For example,

f = e^{F} | (8.2) |

where *f* = finite fractionof a population number removed by
fishing.

Thus, in one year with a finite fishing
mortality rate of 0.4, 40% of the population would be removed by fishing.
However, it is more convenient to work with instantaneous rates in most
situations and the value of instantaneous fishing mortality that would give a
40% removal if applied over a full year is 0.5 (e^{0.5}). Ricker (1975) provides a detailed explanation of
instantaneous rates and their use in fisheries.

The simple mathematical expressions above mask some of the more complex issues relating to mortality rates. For example, it is intuitive that mortality rates are not constant throughout a shark’s life. While sharks are young their small size makes them more susceptible to predation from larger fishes and as sharks reach their maximum age, they are more likely to die of old age than from predation. As a result some researchers have suggested that sharks have a U-shaped natural mortality curve. Similarly, fishing mortality can vary with age due to the size selectivity of fishing gear or differences in the spatial distribution of fish of different ages. These complexities should be kept in mind in relation to the techniques described in this Section.

Despite the importance of quantifying mortality to understanding the dynamics of shark populations, there have been limited amounts of research directed at this topic. The main reason for this is that accurately quantifying mortality rates is difficult and typically requires substantial amounts of data. Since population assessment is such an important part of managing fished or endangered populations, indirect methods of estimating mortality have been developed and are commonly used in the population assessment of sharks and other aquatic organisms. These indirect techniques use relationships between life history parameters and typically, natural mortality from species where research has been undertaken. The relationships used for sharks are based on teleost fishes, although some use data from broader taxonomic groups.

This Section describes methods for estimating mortality rates in shark populations, starting with the simple indirect methods and then discusses the more complex and data intensive direct methods. We have attempted to use examples from the shark literature throughout. We also attempt to point out the strengths and weaknesses of each of the methods and as a conclusion try to provide some guidance on which techniques to use in different situations. The fisheries literature relevant to both direct and indirect methods of estimating natural mortality was reviewed by Vetter (1988) and this reference is a valuable source of information on this topic.

**8.2 INDIRECT METHODS**

**8.2.1 Introduction**

Indirect methods have typically been developed to estimate natural mortality, but in some cases estimates of total mortality can be made. In cases where a method estimates total mortality, e.g. Hoenig (1983) and Brander (1981) can be assumed to be equal to natural mortality when the population is unfished (i.e. F = 0). If the population is fished, then the value of fishing mortality must be known to determine natural mortality. The majority of these indirect methods assume that mortality is independent of age, but two methods that give age-dependent values are also described.

**8.2.2 Age-independent
methods**

*8.2.2.1 Pauly (1980)*

A commonly used indirect method of estimating natural mortality
was described by Pauly (1980). He related natural mortality to von Bertalanffy
growth parameters (L∞or W∞and K) and mean environmental temperature (*T*, in degrees
Celsius). This method assumes that there is a relationship between size
(measured in either length or weight) and natural mortality. This relationship
is quite weak on its own, but the inclusion of mean environmental temperature
increases the fit as an animal living in warmer water will have higher
mortality rates than an equivalent animal living in cooler water (Pauly, 1980).
The relationships developed were based on natural mortality and ambient
temperature data for 175 fish stocks, only two of which were sharks (*Cetorhinus maximus* and *Lamna nasus*). The relationship based on length was

log M = -0.0066 – 0.279 log L + 0.6543 log K + 0.4634 log T_{∞} | (8.3) |

and based on weight was

log M = -0.2107 – 0.0824 log L + 0.6757 log K + 0.4627 log T
135,114_{∞} | (8.4) |

Estimation of natural mortality using these equations is straightforward as long as von Bertalanffy parameter values are available. Jensen (1996) reanalysed the data of Pauly and used this to produce a simpler relationship (Section 8.2.2.4).

*8.2.2.2 Gunderson
(1980) and Gunderson and Dygert (1988)*

Gunderson (1980) used r-K selection theory to develop a relationship between female gonadosomatic index (GSI) and natural mortality. This relationship assumes that there is a strong correlation between the amount of energy that a female invests in reproduction and natural mortality. Gunderson’s original relationship was

M = 4.64GSI -0.370 | (8.5) |

This relationship was based on ten North Sea teleost species and uses maximum female GSI. The calculation of GSI is covered in Section 7 of this manual.

This relationship was refined by
Gunderson and Dygert (1988) who increased the size of the data set on which the
relationship was based to 20 species, including one shark (*Squalus acanthias*).
The new relationship was

M = 0.03 + 1.68GSI | (8.6) |

Simpfendorfer (1999a) used these two
methods in a study of the Australian sharpnose shark (*Rhizoprionodon taylori*).
He found that the method of Gunderson (1980) was a poor predictor of natural
mortality, but that the method of Gunderson and Dygert (1988) was one of only
two methods that produced reasonable values. Simpfendorfer (1999a) pointed out
that the results from this method may be biased since it is assumed that GSI is
a proxy for reproductive investment. Since many sharks are viviparous (such as
*R. taylori*), not all of the reproductive investment is included in the full
size ovarian eggs. Instead, much of the reproductive investment is made later
via the placental (or analogous tissues) connection. Thus, it is more likely
that this method will work better with oviparous and ovoviviparous shark
species.

*8.2.2.3 Hoenig (1983)*

The most widely used indirect method of estimating mortality in shark species is that of Hoenig (1983) (see Section 9). This method uses maximum observed age to predict total mortality, since longer lived species will die at a slower rate than short-lived species. Hoenig (1983) developed three relationships that may be of use to shark researchers (a fourth relationship was developed for mollusks). The most commonly used relationship was for 84 stocks of teleost fishes:

ln Z = 1.46 - 1.01 ln t_{max} | (8.7) |

Hoenig (1983) also developed a relationship for 22 cetacean stocks:

ln Z = 0.941 - 0.873 ln t_{max} | (8.8) |

While this relationship is less useful, it may have some applicability since, like cetaceans, sharks are long-lived, slow-growing and have few young. However, cetaceans are also homeothermic, which may bias the results if applied to sharks.

The third relationship developed by Hoenig (1983) was a combination of all of the mollusk, teleost and cetacean data

ln Z = 1.44 - 0.982 ln tmax | (8.9) |

The values estimated by the relationships of Hoenig (1983) all predict total mortality. As such they can only be used to predict natural mortality when F ≈ 0. Hoenig (1983) also noted that it is possible to use a geometric mean regression in developing the predictive relationships and provided the values for these parameters. However, it has been standard practice for work with sharks to use the simple teleost relationship.

*8.2.2.4 Jensen 1996*

Jensen (1996) used the Beverton and Holt life history invariants (Charnov, 1993) as a starting point in determining the relationships between life history parameters and natural mortality. Using optimal trade-offs between reproduction and survival he showed that

M = 1.65/x_{m} | (8.10) |

where x_{m} is the age at maturity. Similarly, he
showed that there was also a simple theoretical relationship between the von
Bertalanffy *K* value and natural mortality

M = 1.5K | (8.11) |

This relationship is much simpler than that provided by Pauly (1980, see above). Jensen re-analysed Pauly’s data and demonstrated that the simple relationship

M = 1.60K | (8.12) |

gives an equivalent fit to the data as the more complex Pauly equation. This simple relationship is close to the theoretical value (1.5K), suggesting that these relationships may provide a relatively sound method of estimating natural mortality.

*8.2.2.5 Brander’s
equilibrium mortality estimation*

Rather than a method to obtain estimates of total, fishing or
natural mortality, Brander’s (1981) method is an easy way to estimate *threshold* levels of total mortality beyond which stocks will collapse for organisms like
sharks and rays in which the actual number of young produced a year is known.
Brander (1981) proposed a simple and intuitive relationship to estimate if the
total mortality rates of the juvenile and adult portions of a population are
beyond a threshold that would lead to stock collapse. His method relies on
biological information and some assumptions as detailed below. It is a simple
and useful way to perform a quick assessment of the status of exploitation of a
stock. This method can be used not only to rapidly estimate if the fishing rate
is too high, but also to rank species along a continuum of resilience to
exploitation depending on their life-history traits, along similar lines to the
demographic methods developed by Au and Smith (1997) and in Section 9.
Brander’s method borrows the conventions of demographic analysis and considers
only the female part of the population for simplicity.

The method calls for 3 types of information:

- The age of first sexual maturity of the stock. This is usually taken as the age at which 50% of the population is sexually mature. (See section 7.3.3).
- The rate of reproduction (how many offspring are produced a year; in the case of elasmobranchs this would be the number of eggs laid a year for species such as the skates (Rajidae) and sharks of the Heterodontidae and Scyliorhinidae families, or the number of pups a year for live-bearing sharks and rays).
- An estimate of the instantaneous
total mortality rate of the immature part of the stock.
This method relies on two assumptions:

- The rate of reproduction is constant and not related to the age or size of individuals. Although in many species there is a known relationship between maternal size and fecundity, this is not always the case. In other circumstances, an average number of eggs laid or pups produced can be used as an approximation or the limits of the range can be used to place bounds on the uncertainty.
- The mortality rate of the immature stock from birth to sexual maturity is considered to be constant. Although this is a stronger assumption as newborn survival is often much lower than for subsequent ages (Manire and Gruber 1993; Heupel and Simpfendorfer 2002). An estimate of mortality that is representative of the immature part of the stock can be used as this is an approximate method.

Brander’s method is based on the fact that
for a population to remain at a constant level and not decrease or increase in
size (i.e. be in *equilibrium*), the total rate of mortality of adults or mature
fish (Z_{m}) must equal the net rate of recruitment
of mature fish to the stock (R_{m})

Z_{m} = R_{m} | (8.13) |

In turn, the recruitment to the mature stock is equal to the number of eggs developing into females or the number of female pups born multiplied by the survival from birth to maturity

R_{m} = (E/2)e^{-Z}_{i}^{t}_{m} | (8.14) |

where E denotes the rate of reproduction (in number of eggs or
embryos produced a year), Z_{i} is the total mortality of the immature
part of the stock (as mentioned above, Z_{i} is assumed to be constant throughout immature ages) and t_{m} is the number of years from birth to sexual maturity. To
simplify, only females are considered by Brander, usually it is assumed that
half of the total eggs laid or embryos in-utero will develop into females but
it is advisable to check if this applies to the species being analysed.

Thus, for the population to remain in equilibrium

Z_{m} = (E/2)e^{-Z}_{i}^{t}_{m} | (8.15) |

This is Brander’s equation and
substituting the values of the age at maturity, the rate of reproduction and
the total mortality of immature fish for the species being analysed gives the
corresponding equilibrium total mortality rate of the adult stock. This is an
important reference point for management that indicates the maximum level of total
mortality that the adult stock can withstand before the populations starts to
decline. An additional application of this method involves repeating the above
calculations using different values of Z_{i} to calculate equilibrium curves like those seen in Figure8.1. In this figure, the mortality
thresholds (equilibrium instantaneous total mortality rates of mature and
immature fish) of two hypothetical species are plotted. Both species have a t_{m} of 11 years but different rates of reproduction (20 and
40 offspring a year). Mortality values to the right and above each curve will
eventually drive the population to collapse. Thus, if we can independently
determine the actual values of total mortality for the immature and mature
parts of the stock in question (Z_{i} and Z_{m}) and if the values are to the right of the corresponding
curve, management should attempt to reduce total mortality towards an
equilibrium level. Catch curves (Section 8.3.2) can be used to estimate the
level of total mortality for each part of the stock, but if catch curves can be
calculated, then it is usually possible to do a more thorough stock assessment
as discussed in Section 10.

While the two curves in Figure 8.1 illustrate how species with higher fecundity can withstand a slightly higher level of total mortality, they also show that doubling the fecundity has a relatively small effect on the equilibrium mortality. The net rate of recruitment is the most important factor and this depends directly on the cumulative mortality of the immature part of the stock until it reaches maturity.

FIGURE 8.1

**Equilibrium mortality curves for two theoretical shark
populations as a function of total mortality of the mature (Zm) and immature
(Zi) portions of the stock. In both cases the age of first sexual maturity is
11years. Reproductive rate is 40 or 20 offspring a year depending on the
case.**

Brander’s method is an easy and simple
way to estimate the maximum total mortality of the mature stock that would
guarantee the stability of the population based on age of maturity, rate of
reproduction and total mortality of the immature stock. The method was used by
Brander to explain why common rays *Dipturus batis* (=*Raja batis*) were virtually
extirpated in the Irish Sea and to compare the “resilience”to exploitation of
other ray species. For this, he plotted the highest total mortality that could
be sustained by the five species he was analyzing as a function of fecundity
and age of maturity while assuming that Z_{m}=Z_{i}. The results showed that the least
fecund species could withstand the highest mortality because it had a high net
survival to maturity. Brander’s method is useful for deriving reference points
and making comparative analyses; however, it has never been adopted for the
management of an actual elasmobranch fishery.

The main limitations of Brander’s approach are: (a) it does not provide direct management advice in the form of an appropriate catch or effort level and (b) it is not a dynamic model (considering changes in time), but offers only a static view, thus processes like density-dependent compensation cannot be taken into account. Density-dependent compensation is a change in any fundamental process of the population that is directly related to the abundance level of the stock. In reality, most biological processes are density-dependent, especially mortality and recruitment (which is a consequence of pre-recruit mortality), but other processes like body growth, population growth and fecundity are often density-dependent too.

**8.2.3 Age-dependent
methods**

*8.2.3.1 Peterson and
Wroblewski (1984)*

Peterson and Wroblewski (1984) estimate natural mortality that
varies with age using dry weight as a scaling factor. Using particle-size
theory and data from the pelagic ecosystem (including fish larvae, adult fish
and chaetognaths) they showed that the natural mortality for a given weight
organism (M_{w}) is

Mw= 1.92w-^{0.25} | (8.16) |

where w is the dry weight of an organism. To make this estimate of natural mortality age-specific, weight-at-age data is required. This is normally obtained from a length-weight relationship and length-at-age data from a von Bertalanffy growth function. Such an approach yields wet weight and Cortes (2002) suggested that a conversion factor of one fifth be used for sharks to give dry weight. One criticism of this method has been that it was developed for smaller pelagic organisms. However, McGurck (1986) showed that it accurately predicted natural mortality rates over 16 orders of magnitude.

*8.2.3.2 Chen and
Watanabe (1989)*

Chen and Watanabe (1989) recognized that natural mortality in
fish populations, like most animal populations, should have a U-shaped curve
when plotted against age (they referred to it as a bathtub curve). To model
this curve, they used two functions, one describing the falling mortality rate
early in life and a second describing the increasing mortality towards the end
of life. To scale the values of mortality by age (*M(t)*), Chen and Watanabe
(1989) used the k and *t _{0}* parameters of the von Bertalanffy growth
function.

(8.17) |

where

(8.18) |

and

(8.19) |

Cortes (1999) used this method to
estimate the survival of sandbar sharks (*Carcharhinus plumbeus*) by age-class.
He demonstrated no increasing mortality in older age classes due to senescence.
The survival values that Cortes (1999) estimated using this method were similar
to those for the Peterson and Wroblewski (1984), Hoenig (1983) and Pauly (1980)
methods. Unlike the Peterson and Wroblewski (1984) method the Chen and Watanabe
(1989) method only requires von Bertalannfy parameters, but the mathematics are
more involved. This technique can be simply implemented in a spreadsheet using
the formulae provided (8.17–8.19).

**8.2.4 Other indirect
methods**

The indirect methods described above represent the most commonly used approaches in the elasmobranch literature. However, the fisheries literature contains many other similar techniques that researchers may wish to investigate. These include Ursin (1967), Alverson and Carney (1975), Blinov (1977) and Myers and Doyle (1983). In addition, there are a number of studies that have looked at problems associated with these techniques such as Barlow (1984) and Pascual and Iribarne (1993).

**8.3 DIRECT METHODS**

**8.3.1 Requirements**

Direct methods provide the researcher with the best estimates of mortality because they are based on the actual stock in question. However, they are also data intensive and require unbiased data. Thus, it is important that data are collected so that they are statistically appropriate and that the assumptions and restrictions of each of the methods are understood.

**8.3.2 Catch curves**

One powerful method of estimating total mortality (i.e. natural mortality if F = 0) is the use of catch curves. Catch curve analysis assumes that the decrease in observed numbers of individuals across the age-structure of the population is the result only of mortality:

N_{t+1}= N_{t}e^{-Z} | (8.20) |

Thus, if the numbers of individuals in each age class are known, mortality can be estimated. This method requires age data from an unbiased sample of a population and involves six steps:

- The number of animals in each class is determined.
- The numbers are log (base e) transformed.
- The log-transformed numbers are plotted against age.
- A linear regression is fitted to the descending limb (right hand side) of the catch curve.
- The value of total mortality is calculated as the negative slope of the regression.
- The error of the estimates is calculated as the error of the slope of the regression.

An example of catch curves from male and
female Australian sharpnose sharks (*Rhiozprionodon taylori*) from Simpfendorfer
(1999a) is given in Figure8.2.

FIGURE 8.2**Catch curves for (A) male and (B) female Australian
sharpnose sharks derived from data from Simpfendorfer (1993). Data points for
the first age class were not used to calculate the regression line. From
Simpfendorfer (1999a).**

One of the most important steps in the
application of this method is the selection of the points on the descending
limb of the catch curve. In the perfect situation the catch curve would be a
linear set of points with a negative slope (Figure 8.3a.). However, in reality
most catch curves have an ascending limb for the youngest age classes, due to
incomplete recruitment of some age classes to the fishing gear or to the
available population and an asymptote for the older age classes (Figure 8.3b).
Ricker (1975) suggested using only the points to the right of the peak ln (N)
value. It is also possible to exclude points that are clearly outliers from the
line described by most of the descending limb points. This approach was used by
Cortes and Parsons (1996) for the bonnethead shark (*Sphyrna tiburo*). In
situations where there are only limited numbers of age classes including as
many points as possible will provide the most accurate result with the lowest
error. To do this, Simpfendorfer (1999a) fitted both a linear and quadratic
function to the points including the peak ln (N) value (that Ricker (1975)
suggested excluding). When the quadratic function provided a significant
increase in fit, it was assumed that including the maximum point increased
curvature in the data and so the maximum point was excluded.

The use of catch curves requires a number of assumptions to be made about the sampled population. First, the aged animals are representative of the age-structure in the population. Second, the ages are accurately determined. Third, the total mortality rate is constant across the age classes to which the linear function is fitted. Fourth, the mortality rate is constant between years (if more than one year’s data are used). Fifth, recruitment is constant between years. Last, vulnerability to fishing gear is equal for all ages and constant over year classes.

FIGURE 8.3**Hypothetical catch curves from (a) the “perfect”case based
on N_{t+1}= N_{t}e^{-Z} where Z is constant and the regression can be fitted to
all points, and (b) a more typical situation where the regression is fitted
only to points to the right of the maximum ln (number) value.**

Often it is difficult to get a sufficiently large sample of aged animals from a population to get accurate estimates of mortality. However, there may be sufficient age data to develop an age-length (or weight) key. This age-length key can be used to assign ages based on length. More details of age-length keys can be found in Hilborn and Walters (1992). Cortes and Parsons (1996) used an age-based catch curve and an age-length key derived catch curve for the bonnethead shark. Both methods produced similar results.

**8.3.3 Tagging**

Tagging experiments can be separated into two general
categories: (a) studies where the tagged individuals of
population are killed upon recapture, as in a commercial fishery and (b) studies where tagged individuals are recaptured and released
several times. The former are referred to as tag-recovery studies as evident by
the fact that fishers recover tags of individuals that are harvested, while the
latter are referred to as capture-recapture studies since it is possible to
recapture tagged individuals on multiple occasions. Moreover, tag-recovery
studies are typically viewed as fishery-dependent since the data obtained is
strictly a function of fishing activities, while for capture-recapture studies
it is best to use a fishery-independent sampling design to generate capture
histories for tagged individuals. Here we focus on the use of multiyear
tag-recovery studies as a method to derive estimates of mortality and note that
there is a wealth of literature on the analysis of capture-recapture data (e.g.
Burnham *et al.*, 1987, Pollock *et al.*, 1990)

The general structure of a multi-year tag-recovery study is to tag Niindividuals at the start of each year i, for i = 1,…, I years. Tagging periods do not necessarily have to be yearly intervals; however, data analysis is easiest if all periods are the same length and all tagging events are conducted at the beginning of each period. A total of rijtag-recoveries are then tabulated during year j from the cohort released in year i, with j = i, i+1, …, J and J ≥ I (here, the term “cohort”refers to a batch of similar (e.g. similarly-sized) individuals tagged and released at essentially the same time). The tabulated multi-year tag-recoveries can be displayed in an upper triangular matrix of the following form

(8.21) |

Application of multi-year tag-recovery models involves
constructing a matrix of expected values and comparing them to the observed
data. The matrix of expected values corresponding to the time-specific
parameterization of Brownie *et al.* (1985), which is referred to as Model 1,
takes the form

(8.22) |

where f_{i} is the tag-recovery rate in year *i*,
which is the probability a tagged individual alive at the beginning of year i
is caught during year *i* and its tag is recovered; S_{i} is the annual survival rate for year i, which is the probability an individual survives to the end of year *i*, and

(8.23) |

Although Model 1 is not the most general
formulation of the Brownie *et al.* (1985) models, it is the most commonly
applied since it possesses the flexibility to document annual changes in the
tag-recovery and survival rates. In addition to the Brownie *et al.* (1985)
formulation, there are two other types of models (not described here) that can
be used to analyse multiyear tag-recovery data (see Seber, 1970 and Hoenig *et
al.*, 1998a,b).

Since the data in each row of the
tag-recovery matrix follow a multinomial probability distribution, the method
of maximum likelihood can be used to derive parameter estimates. Also, since
all tagged cohorts are assumed to be independent, an overall likelihood
function can be constructed as the product of the individual likelihood
functions corresponding to each row of the tag-recovery matrix (Brownie *et al.*,
1985; Hoenig *et al.*, 1998a). Software packages that numerically maximize
product multinomial likelihood functions have been developed for the use of
tag-recovery models. These include programs SURVIV (White 1983;
*http://www.mbr-pwrc.usgs.gov/software*) and MARK (White and Burnham 1999;
*http://www.cnr.colostate.edu/~gwhite/mark/mark.htm*).

Application of the Brownie *et al.* (1985)
models requires the following assumptions: (a) the tagged sample is
representative of the target population; (b) there is no tag loss or, if tag
loss occurs, a constant fraction of the tags from each cohort is lost and all
tag loss occurs immediately after tagging; (c) the time of recapture of each
tagged individual is reported correctly (i.e. all tags are returned by fishers
during the year in which the individuals were harvested); (d) all tagged
individuals within a cohort experience the same annual survival and
tag-recovery rates; (e) the decision made by a fisher on whether
or not to return a tag does not depend on when the individual was tagged; (f)
survival rates are not affected by tagging process or, if they are, the effect
is restricted to a constant fraction dying immediately after tagging, (g) and
the fate of each tagged individual is independent of the other tagged
individuals.

Tag-recovery studies can be plagued by (among others) the following problems:

- Newly tagged individuals may not
have the same spatial distribution as previously tagged individuals, especially
if tagging takes place in only a few locations. (Note - it is best to tag fewer
individuals over a large number of locations rather than many individuals at
just a few locations.) This problem of non-mixing (Hoenig
*et al.*, 1998b) constitutes a violation of assumption (a) and will lead to unreliable parameter estimates. To determine if non-mixing is present, Latour*et al.*(2001a) developed a test that can be applied prior to data analysis. - Individuals are tagged across a range of ages and, or sizes and these different age and, or size groups experience different survival rates due to selectivity of the harvest. This leads to a violation of assumption (d).
- Individuals within a particular
tagged cohort have a different spatial distribution than the other individuals
within that cohort, perhaps due to age-and, or size-specific migration
patterns (e.g. individuals may leave the estuarine or near coastal nursery
grounds once they become sexually mature). This leads to a violation of
assumptions (a) and (d) and can be accounted for during data analysis by
ignoring the data associated with portions of the tag-recovery matrix (for more
details, see Latour
*et al.*, 2001b).

Although the Brownie *et al.* (1985)
models are simple and robust, they do not yield direct information about
year-specific instantaneous rates of mortality (equation 8.1) or even
exploitation rates (*u _{i}*), which are often of interest to
fisheries managers. Estimates

Si= e^{-Z}_{i} | (8.24) |

and if information about M is available (e.g. from one of the
methods previously described), then estimates of *F _{i}* are possible. Given estimates of the instantaneous rates, it is
then possible to estimate

for Type I fishery | (8.25) | |

for Type II fishery |

Alternatively, if estimates of the
instantaneous rates of mortality are unavailable, it is still possible to
calculate year-specific estimates of exploitation (Pollock *et al.*, 1990, Hoenig
*et al.*, 1998a) by

(8.26) |

where *f* is the short-term probability an individual survives the
handling and tagging process with the tag intact and l is the tag-reporting
rate (i.e. probability the tag will be reported given that that individual is
harvested). The parameter *f* can be estimated by holding newly tagged
individuals in cages or holding pens for a short period of time (e.g. 2–4 days)
(Latour *et al.*, 2001b), while the tag-reporting rate is best estimated by
conducting a high-reward study (Henny and Burnham, 1976; Pollock *et al.*, 2001).

Regardless of the goals of a particular tag-recovery
study (e.g. to estimate S_{i}, F_{i}, etc.), it is advisable to assess the likelihood of assumption
violation. This can involve either conducting auxiliary studies to address
specific assumptions (e.g. experiments that allow estimation of the rates of
tag-induced mortality, both short-term and chronic tag shedding, tag reporting,
etc.) and, or by using diagnostic tools to assess model performance (Latour et
al., 2001c). A variety of techniques specific to shark tagging studies have
been used to assess and adjust for assumption violation. For example,
Simpfendorfer (1999b) described a method of correcting dusky shark tag return
rates for non-reporting by using compulsory catch information and the reporting
rates of individual fishers. Xiao (1996) described a model for estimating
shedding rates from a double tagging experiment with Australian blacktip sharks
(*Carcharhinus tilstoni*); Xiao *et al.* (1999) described the tag-shedding rates of
school (*Galeorhinus galeus*) and gummy (*Mustelus antarcticus*) sharks.

The use of tagging experiments can provide one of the best methods of estimating both fishing and natural mortality rates in shark populations. There are a wide variety of techniques available for the analysis of these types of data. The increased computing power available to most scientists and the development of software packages has enabled increasingly powerful techniques. These techniques, however, have been rarely used for shark populations. Grant, Sandland and Olsen (1979) estimated the fishing and natural mortality rates of school sharks using animals released in the 1950s. Simpfendorfer (1999b) estimated fishing mortality rates of juvenile dusky sharks based on tag recaptures in a commercial gillnet fishery and Xiao, Stevens and West (1999) estimated fishing and natural mortality rates of the school shark using a probabilistic model.

**8.3.4 Telemetry**

Terrestrial biologists often use telemetry methods to estimate
mortality rates by regularly monitoring the status of individuals in a
population. Despite their popularity in terrestrial biology, these approaches
have rarely been used in aquatic studies. In terrestrial systems radio
frequency telemetry methods are used that can locate individuals over
relatively large distances, whereas in aquatic systems acoustic telemetry
methods that have relatively short reception distances must normally be used.
This limited reception distance and the large ranges of individuals makes most
systems impractical for monitoring the status of individuals. Only one study of
a shark population has used this technique. Heupel and Simpfendorfer (2002)
used data from an acoustic monitoring system in a nursery area for blacktip
sharks (*Carcharhinus limbatus*) to estimate both natural and fishing mortality
rates. They used analytical techniques described by Hightower, Jackson and
Pollock (2001) (Kaplan-Meier and Program SURVIV) to estimate mortality rates
for the 0+ segment of the population through time. This type of approach
provides some of the most detailed understanding of the mortality process in a
population (Figure 8.4), but requires a large amount of data and a high level
of effort in the field. The success of the approach used by Heupel and
Simpfendorfer (2002) in estimating mortality rates was due to the use of an
array of data-logging acoustic monitors that continuously recorded the activity
of up to 42 sharks a season within the relatively small and well-confined study
site. Heupel and Simpfendorfer (2002) and Hightower, Jackson and Pollock (2001)
provide more details of this approach.

**8.3.5 Others**

Cohort analysis is a popular method of estimating mortalities in
fish populations. This often takes the form of Virtual Population Analysis
(VPA), but also includes a method described by Paloheimo (1980) that bases
mortality estimates on reductions in catches of a single cohort over time.
Although commonly used in studies of teleost fish populations, these techniques
have rarely been used in shark populations studies. Smith and Abramson (1990)
used a reverse VPA to estimate the fishing mortality rates of leopard shark
(*Triakis semifasciata*). Walker (1992) used the technique described by Paloheimo
(1980) to estimate the natural mortality of gummy sharks as did Campana *et al.*
(2002) to estimate total mortality in porbeagle sharks (*Lamna nasus*). These
types of analysis are rarely used in studies of shark populations as the data
requirements, in terms of the catch-at-age and fishing effort information, are
greater than are normally available. However, for populations where good data
are available this type of approach can yield valuable information on
mortality.

FIGURE 8.4**Kaplan-Meier estimates of finite rate of survival from (a)
natural mortality and (b) fishing mortality for juvenile blacktip sharks (data
for 1999–2001 summers combined). Dashed lines indicate 95% confidence
intervals. Graphs use the second week of May as week 1 (from Heupel and Simpfendorfer, 2002).**

**8.4 CONCLUSIONS AND
ADVICE**

The first choice that a researcher needs to make is whether to use a direct or an indirect method to estimate mortality. Early in the assessment of a population indirect methods are used as they can provide quick and easy results, especially for inclusion in a model. When indirect methods are used for input into a model it is prudent to construct multiple models that use as many of the indirect estimates as possible. This allows the researcher to include an understanding of the uncertainty associated with the estimates. Each method will provide different results and in most instances there is no information that can be used to choose between the different values (i.e. they are all equally likely). In some cases there is little difference between methods. For example, Simpfendorfer (1999b) used five different methods for dusky sharks and all but one of the results fell within the range of 0.081 to 0.086. Alternatively, the estimates of different methods can be very variable. Simpfendorfer (1999a) used seven methods for the Australian sharpnose shark and found a range of values from 0.56 to 1.65.

One first obvious result in population assessments is that the results are always dependent upon the values of mortality used (both F and M). Thus, as a researcher tries to make an assessment more precise and accurate, a direct estimate of mortality will provide a higher level of certainty about the results. It is at this point that direct methods of estimating mortality are normally applied. Unlike indirect methods direct estimates require a sampling strategy for the specific species to ensure satisfactory results. Thus, they require a much larger amount of field work and data analysis. The reward for this work can be a much better understanding of mortality in a population and so a more accurate assessment of its status.

The choice between different direct methods depends on a couple of factors. Tagging studies probably provide the best data if they can be implemented properly. Of particular importance is the ability to get tag recapture information, tag shedding rates and tag reporting rates. Without these types of data the estimates of mortality will be biased and may yield results no more accurate than the indirect methods. In situations where tag recapture data may be more difficult to obtain the catch curve approach may prove more useful. Catch curves can produce accurate results, but the data must meet several assumptions (Section 8.3.2) to do so. Finally, telemetry methods are best used in situations where the mortality within a given system is required and the system can be adequately sampled acoustically, normally with data-logging monitors. While a telemetry approach may seem like a dream for some populations, technological and methodological advances are being made that will make this more and more available to researchers. As such, it is likely to represent the future for the estimation of mortality in many situations.

**8.5 LITERATURE CITED**

**Alverson, D.L. & Carney, M.J.**
1975.
A graphic review of the growth and decay of population cohorts. *J. Cons. Int.
Explor. Mer.*, 36: 133–143.

**Au, D.W. & Smith, S.E.** 1997. A
demographic method with population density compensation for estimating
productivity and yield per recruit of the leopard shark (Triakis semifasciata).
*Canadian Journal of Fisheries and Aquatic Sciences*, 54: 415–420.

**Barlow, J.** 1984. Mortality estimation:
biased results from unbiased ages. *Canadian Journal of Fisheries and Aquatic
Sciences*, 41: 1843–1847.

**Blinov, V.V.** 1977. The connection
between natural mortality and reproduction of food fishes and modelling of the
processes involved. *Journal of Ichthyology*, 16: 1033–1036.

**Brander, K.** 1981. Disappearance of
common skate *Raia batis* from Irish Sea. *Nature*, 290:48–49.

**Brownie, C., Anderson, D.R., Burnham,
K.P. & Robson, D.S.** 1985. *Statistical inference from band recovery data: a
handbook, 2nd ed*. U.S. Fish and Wildl. Serv. Resour. Publ. No. 156.

**Burnham, K.P., Anderson, D.R., White,
G.C., Brownie, C. & Pollock, K.H.** 1987. Design and analysis methods for
fish survival experiments based on release-recapture. *American Fisheries
Society*, Monograph 5, Bethesda, Maryland.

**Campana, S.E., Joyce, W., Marks, L.,
Natanson, L.J., Kohler, N.E., Jensen, C.F., Mello, J.J. & Pratt, Jr., H.L.**
2002. Population dynamics of the porbeagle in the northwest Atlantic Ocean.
*North American Journal of Fisheries Management*, 22: 106–121.

**Charnov, E.** 1993. *Life history
invariants*. Oxford University Press, New York.

**Chen, S. & Watanabe, S.** 1989. Age
dependence of natural mortality coefficient in fish populations
dynamics.
*Nippon Suisan Gakkaishi*, 55: 205–208.

**Cortes, E.** 1999.
A
stochastic stage-based population model of the sandbar shark in the Western
North Atlantic. In J.A. Musick (ed.). *Life in the slow lane*. Ecology and
conservation of *long-lived marine animals*, pp. 115–136. American Fisheries
Society Symposium 23, Bethesda, Maryland.

**Cortes, E.** 2002. Incorporating uncertainty
into demographic modeling: application to shark populations and their
conservation. *Conservation Biology*, 16: 1048–1062.

**Cortes, E. & Parsons, G.R.** 1996.
Comparative demography of two populations of the bonnethead shark (*Sphyrna
tiburo*). *Canadian Journal of Fisheries and Aquatic Sciences*, 53: 709–718.

**Grant, C.J. Sandland, R.L. & Olsen,
A.M.** 1979. Estimation of growth, mortality and yield per recruit of the
Australian school shark, Galeorhinus australis (Macleay), from tag recoveries.
*Australian Journal of Marine and Freshwater Research*, 30: 625–637.

**Gunderson, D.R.** 1980. Using r-K
selection theory to predict natural mortality. *Canadian Journal of Fisheries
and Aquatic Sciences*, 37: 2266–2271

**Gunderson, D.R. & Dygert, P.H.** 1988.
Reproductive effort as a predictor of natural mortality rate. *J. Cons. Int.
Explor. Mer.*, 44: 200–209.

**Henny, C.J. & Burnham, K.P.** 1976. A
reward band study of mallards to estimate band reporting rates. *Journal of
Wildlife Management*, 40: 1–14.

**Heupel, M.R. & Simpfendorfer, C.A.**
2002. Estimation of mortality of juvenile blacktip sharks, *Carcharhinus
limbatus* within a nursery are using telemetry data. *Canadian Journal of
Fisheries and Aquatic Sciences*, 59: 624–632.

**Hightower, J.E., Jackson, J.R. &
Pollock, K.H.** 2001. Use of telemetry methods to estimate natural and fishing
mortality of striped bass in Lake Gaston, North Carolina. *Transactions of the
American Fisheries Society*, 130: 557–567.

**Hilborn, R. & Walters, C.J.** 1992.
Quantitative fish stock assessment. Choice, dynamics and uncertainty. Chapman
and Hall, New York. 570 pp.

**Hoenig, J.M.** 1983. Empirical use of
longevity data to estimate mortality rates. *Fish. Bull.*, 82: 898–903.

**Hoenig, J.M. Barrowman, N.J., Hearn,
W.S. & Pollock, K.H.** 1998a. Multiyear tagging studies incorporating fishing
effort data. *Canadian Journal of Fisheries and Aquatic Sciences*, 55: 1466–1476.

**Hoenig, J.M. Barrowman, N.J., Pollock, K.H., Brooks, E.N., Hearn, W.S. & Polacheck, T.** 1998b. Models for tagging
data that allow for incomplete mixing of newly tagged animals. *Canadian Journal
of Fisheries and Aquatic Sciences*, 55: 1477–1483.

**Jensen, A.L.** 1996. Beverton and holt
life history invariants result from optimal trade-off of reproduction and
survival. *Canadian Journal of Fisheries and Aquatic Sciences*, 53:820–822.

**Latour, R.J., Hoenig, J.M., Olney, J.E.
& Pollock. K.H.** 2001a. A simple test for nonmixing in multiyear tagging
studies: application to striped bass tagged in the Rappahannock River,
Virginia. *Transactions of the American Fisheries Society*, 130: 848–856.

**Latour, R.J., Pollock, K.H., Wenner,
C.A. & Hoenig, J.M.** 2001b. Estimates of fishing and natural mortality for
red drum (*Sciaenops ocellatus*) in South Carolina waters. *North American Journal
of Fisheries Management*, 21: 733–744.

**Latour, R.J., Hoenig, J.M., Olney, J.E.
& Pollock, K.H.** 2001c. Diagnostics for multi-year tagging models with
application to Atlantic striped bass (*Morone saxatilis*). *Canadian Journal of
Fisheries and Aquatic Sciences*, 58: 1716–1726.

**Manire, C.A. & Gruber, S.H.** 1993.
A
preliminary estimate of natural mortality of age-0 lemon sharks, Negaprion
brevirostris. In S. Branstetter (ed.). *Conservation Biology of Elasmobranchs*,
pp. 65–71. NOAA Technical Reports NMFS.

**Mcgurk, M.D.** 1986. Natural mortality of
marine pelagic fish eggs and larvae: role of spatial patchiness. *Marine Ecology
Progress Series*, 34: 227–242.

**Myers, R.A. & Doyle, R.W.** 1983.
Predicting natural mortality rates and reproduction-mortality trade-offs from
fish life history data. *Canadian Journal of Fisheries and Aquatic Sciences*, 40:
612–620.

**Paloheimo, J.E.** 1980. Estimation of
mortality rates in fish populations. *Transactions of the American Fisheries
Society*, 109: 378–386.

**Pascual, M.A. & Iribarne, O.O.** 1993.
How good are empirical predictions of natural mortality? Fish. Res., 16: 17–24.

**Pauly, D.** 1980. On the
interrelationships between natural mortality, growth parameters, and mean
environmental temperature in 175 fish stocks. *J. Cons. Int. Explor. Mer.*,
39:175–192.

**Peterson, I. & Wroblewski, J.S.**
1984. Mortality rate of fishes in the pelagic ecosystem. *Canadian Journal of
Fisheries and Aquatic Sciences*, 41: 1117–1120.

**Pollock, K.H., Nichols, J.D., Brownie,
C. & Hines, J.E.** 1990. *Statistical inference for capture-recapture
experiments*. Wildlife Monographs 107.

**Pollock, K.H., Hoenig, J.M., Hearn, W.S.
& Callingaert, B.** 2001. Tag reporting rate estimation: 1. An evaluation of
the high-reward tagging method. *North American Journal of Fisheries Management*,
21: 521–532.

**Ricker, W.E.** 1975. Computation and
interpretation of biological statistics of fish populations. *Bull. Fish. Res.
Bd Can.*, 191: 1–382.

**Seber, G.A.F.** 1970. Estimating
time-specific survival and reporting rates for adult birds from band returns.
*Biometrika*, 57: 313–318.

**Simpfendorfer, C.A.** 1993. Age and growth
of the Australian sharpnose shark, *Rhizoprionodon taylori*, from north
Queensland, Australia. *Environmental Biology of Fishes*, 36: 233–241.

**Simpfendorfer, C.A.** 1999a. Mortality
estimates and demographic analysis for the Australian sharpnose shark,
*Rhizoprionodon taylori*, from northern Australia. *Fishery Bulletin*, 97: 978–986.

**Simpfendorfer, C.A.** 1999b. Demographic
analysis of the dusky shark fishery in southwestern Australia. In J.A. Musick
(ed.). *Life in the slow lane. Ecology and conservation of long-lived marine
animals*, pp. 149–160. American Fisheries Society Symposium 23, Bethesda,
Maryland.

**Smith, S.E. & Abramson, N.J.** 1990.
Leopard shark *Triakis semifasciata* distribution, mortality rate, yield, and
stock replenishment estimates based on a tagging study in San Francisco Bay.
*Fishery Bulletin*, 88: 371–381.

**Ursin, E.** 1967. A mathematical model of
some aspects of fish growth, respiration and mortality. *Journal of the
Fisheries Research Board of Canada*, 24: 2355–2390.

**Vetter, E.F.** 1988. Estimation of natural
mortality in fish stocks: a review. *Fishery Bulletin*, 86: 25–43.

**Walker, T.I.** 1992. Fishery simulation
model for sharks applied to the gummy shark, *Mustelus antarcticus* Gunther, from
southern Australian waters. *Australian Journal of Marine and Freshwater
Research*, 43: 195–212.

**White, G.C.** 1983. Numerical estimation
of survival rates from band-recovery and biotelemetry data. *Journal of Wildlife
Management*, 47: 716–728.

**White, G.C. & Burnham, K.P.** 1999.
Program MARK: survival estimation from populations of marked animals. *Bird
Study*, 46: 120–138.

**Xiao, Y.** 1996. A general model for
estimating tag-specific shedding rates and tag interactions from exact or
pooled times at liberty for a double tagging experiment. *Canadian Journal of
Fisheries and Aquatic Sciences*, 53; 1852–1861.

**Xiao. Y., Stevens, J.D. & West, G.J.** 1999. Estimation of fishing and natural mortalities from tagging experiments
with exact or grouped times at liberty. *Canadian Journal of Fisheries and
Aquatic Sciences*, 56: 868–874.

**Xiao, Y., Brown, L.P., Walker, T.I.
& Punt, A.E.** 1999. Estimation of instantaneous rates of tag shedding for
school shark, *Galeorhinus galeus*, and gummy shark, *Mustelus antarcticus*, by
conditional likelihood. *Fishery Bulletin*, 97: 170–184.
